MODEL: ELPS2
Regular price $2,252.71
/
  • One-piece, 48" wide with trap cover, 16 gauge type 304 stainless steel, wash sink with a satin finish.
  • The radiused interior surface makes it easy to clean.
  • The deck is pre-drilled at each station with a three-hole punching for a 4" centerset faucet.
  • Basin is formed to facilitate drainage and is punched to accept a 1-1/2" Drain Assembly.
  • The deck includes a 1 3/8" knockout for an optional Soap Dispenser.
  • Pre-drilled backsplash return is provided for mounting to a reinforced wall.
  • Optional faucets meet NSF/Lead-Free standards and include a 0.5 gallons (1.9 liters) per minute flow control.
  • Uniform Plumbing Code (UPC), National Plumbing Code of Canada (cUPC), ASMEA 112.19.3 compliance.

Features-

  • Sink Type: Permanent
  • Water Supply: Building Water/Hose Supply
  • Water Drainage: Building Drainage/Hose Waste
  • Sink Assembly: Ships flat in a box - Assembly Required
Shipping calculated at checkout.

Additional Info

Submittal ELPS1 and ELPS2 Basin (pdf) Its cost-effective, space-saving design is ideal for use in buildings of all types to expand hand washing capabilities.
Manual ELPS1 or ELPS2 Basin ELPS and ELP2 Installation, Operations & Maintenance Manual
